Paper weight 40-80gsm
Paper width 260-960mm
Bag length 220-850mm
Bag width 80-350mm
Speed 60-400pcs/min
Power 8kw
Weight 5200kg
Machine dimensions(Lx W x H) 5300*2100*2000mm
Production Precision ±0.2mm
Maximum Materials Feeding Width 260-960mm
Maximum Materials Feeding Diameter ≤ 1000mm
2 sets Servo motor: made in Japan Brand: YASKAWA
1 set PLC: made in Taiwan Brand:DELTA
1 set Touch Screen :made in Taiwan Brand: WEINVIEW/DELTA
1 pcs Photo eye: Made in Germany Brand: SICK
1 set EPC: made in China
1 set auto tension in China
Hydraulic auto loading with air shaft
inline two color flexo printing part
1. max width of substrate :1000mm
2. max printing width:950mm
3. range of printing length:240-850mm
4. speed :50m/min
5. heating power:3kw
Spare parts
Feeding pulley 2 PCS,Folding guide pulley 4 PCS,Synchronous belt 1SET=9pcs
CONVOYER BELT 2 PCS,Teeth blade UP 2 PCS+DOWN 2PCS ,Bottom folding blade UP 1 PCS+DOWN 2PCS,Button 5pcs,Switch 5pcs,relay 24v 3pcs , toolbox 1set
