Parameters And Parts
Paper weight 40-80gsm
Bag length 160-420mm
Bag width 80-260mm
Speed 60-400pcs/min
Power 8kw
Weight 3500kg
Machine dimensions(LxWxH)5000*2100*2000mm
Production Precision ±0.2mm
Maximum Materials Feeding Width 260-840mm
1 set PLC: made in Taiwan Brand:DELTA
1 set Touch Screen :made in Taiwan Brand: WEINVIEW/DELTA
1 pcs Photo eye: Made in Germany Brand: SICK
2. max printing width:750mm
3. range of printing length:200-450mm
4. speed :50m/min
CONVOYER BELT 2 PCS,Teeth blade UP 1 PCS+DOWN 1PCS
Bottom folding blade UP 1 PCS+DOWN 1PCS,toolbox 1set
Paper weight 40-80gsm
Bag length 160-420mm
Bag width 80-260mm
Speed 60-400pcs/min
Power 8kw
Weight 3500kg
Machine dimensions(LxWxH)5000*2100*2000mm
Production Precision ±0.2mm
Maximum Materials Feeding Width 260-840mm
Maximum Materials Feeding Diameter ≤ 1000mm
2 sets Servo motor: made in Japan Brand: YASKAWA1 set PLC: made in Taiwan Brand:DELTA
1 set Touch Screen :made in Taiwan Brand: WEINVIEW/DELTA
1 pcs Photo eye: Made in Germany Brand: SICK
1 set EPC: made in China
Inline two color flexo printing part
1. max width of substrate :750mm2. max printing width:750mm
3. range of printing length:200-450mm
4. speed :50m/min
5. heating power:5kw
Spare parts
Feeding pulley 2 PCS,Folding guide pulley 4 PCS,Synchronous belt 1SET=9pcsCONVOYER BELT 2 PCS,Teeth blade UP 1 PCS+DOWN 1PCS
Bottom folding blade UP 1 PCS+DOWN 1PCS,toolbox 1set
